Description
Features:
1. 49 sample positions
2. 56 reagent positions.
3. 120 reaction cuvettes.
4. 400 tests per hour.
5. Probe with anti-collision function, liquid level dectection function.
Technical Parameters:
| Model |
BK-410 |
Overall
Performance |
Throughput |
400 Tests/hour, ISE(Optional) |
| Analysis Method |
End-point, Fixed-time, Rate(Kinetic), Turbidimetry |
| Certificates |
CE, FDA, ISO9001, ISO14001, ISO13485 |
| System |
Optional open or close system, continuous working for 24 hours |
| Sample&Reagent System |
Sample Positions |
49 sample positions |
| Reagent Position |
56 reagent positions |
| Sample Volume |
2~70μl |
| Reagent Volume |
20~350μl |
| Probe |
With anti-collision function, liquid level detection function |
| Probe Washing |
Automatic washing interior and exterior |
| Reagent Cooling |
2~12℃ for 24 hours |
| Reaction System |
Temperature Control |
37±0.2℃, real-time monitoring |
| Cuvettes |
120 reusable cuvettes |
| Mixer Probe |
Independent stirring, automatic frequency conversion |
| Washing |
Automatic cuvettes washing |
| Optical System |
Light Source |
Halogen lamp, water-cooling |
| Spectrophotometry |
Post-spectral spectrophotometry |
| Wavelength |
340~800nm, ＜±1nm |
| Absorbance |
0~3.5Abs |
| Calibration&QC |
Calibration |
Linear: K factor, 1-point, 2-point and multipoint linear
Non-Linear: Spline, Polygon, Index, Ogarithm, Logit-4P, Logit-5P |
| Quality Control |
Real-time QC, Westgard multi rule, Cumulative sum check, Twin plot(2D) |
| Data Management |
Software |
Windows 7/8/10, 32 or 64 bit |
| LIS System |
Bi-direction, support HL7 protocol |
| Interface |
LAN port access |
| Printer |
External, multiple reporting mode available |
| Working Conditions |
Power Supply |
AC220V±10%, 50/60Hz(Standard)
110V±10%, 60Hz(Optional), 650VA |
| Temperature |
15~30℃(±2℃) |
| Water Consumption |
Deionized water＜11L/h |
| Humidity |
40~85% |
| Size&Weight |
External Size(W*D*H) |
973*645*520mm |
| Net Weight |
96kg |
| Package Size(W*D*H) |
1120*780*1035mm |
| Gross Weight |
141kg |
